Product Description
About the aluminum
7075-T6 aluminum alloy hardness is 150HB, belongs to the high hardness aluminum alloy. 7075T6 aluminum alloy is precision machined aluminum in the United States, one of the most commercially available alloys. The main alloying element of 7075 series is zinc, which has strong strength, good mechanical properties and anode reaction. 7075 aluminum heat treatment is because zinc is the main alloying element in 7075, adding magnesium to the alloy containing 3%-7.5% zinc can form a significant strengthening effect of MgZn2, so that the heat treatment effect of the alloy is far better than the al-zinc binary alloy; With the increase of zinc and magnesium content, the tensile strength of the alloy will be further improved, but its resistance to stress corrosion and spalling corrosion will decrease.
Aluminum is a silver-white light metal, relatively soft, density 2.7g/cm3, melting point 660.4℃, boiling point 2467℃,
Aluminum is a silver-white light metal, relatively soft, density 2.7g/cm3, melting point 660.4℃, boiling point 2467℃, aluminum and aluminum alloys have many excellent physical properties, has been very widely used. Aluminum has good reflection performance of light, reflecting ultraviolet light is stronger than silver, the purer aluminum is, its reflection ability is better, and the method of vacuum aluminum plating is commonly used to make high-quality mirrors. Vacuum aluminized film combined with polysilicon film becomes a cheap and lightweight solar cell material. Aluminum powder can maintain a silvery luster, often used to make paint, commonly known as silver powder. Pure aluminum conducts electricity very well, second only to silver and copper. In the electric power industry, it can replace part of copper for wires and cables. Aluminum is a good conductor of heat. It can be used to make various heat exchangers, heat dissipating materials and civil cookers in industry. Aluminum has good ductility, can be drawn into a fine wire, rolled into a variety of aluminum products, but also can be made into thinner than 0.01mm aluminum foil, widely used in packaging cigarettes, candy, etc.. Aluminum alloy has some better properties than pure aluminum, which greatly expands the application range of aluminum. For example, pure aluminum is soft, when a certain amount of copper, magnesium, manganese and other metals are added to aluminum, the strength can be greatly improved, almost equivalent to steel, and the density is small, not easy to rust, widely used in aircraft, cars, trains, ships, artificial satellites, rockets manufacturing. At -196 ° C, some steel is as brittle as glass, while some aluminum alloys increase in strength and toughness, making them cheap and lightweight cryogenic materials that can be used to store liquid oxygen and hydrogen for rocket fuel.
PRODUCT
| Standard | ASTM GB JIS AISI,EN |
| Thickness | 0.006mm(6micron) - 0.2mm (200micron) |
| Width | 120- 1500 mm (tolerance:± 1.0mm) |
| Temper | O,F, H12, 114,H18,H22, H24,H26,H32, etc |
| Application |
Aluminum foil is widely used in food, beverage, cigarette, medicine, photographic plate, household articles, etc. It is usually used as its packaging material, electrolytic capacitor materials, insulation materials for buildings, vehicles, ships and houses. |
| Price Term | Ex-work, FOB, CFR, CIF, etc |
| Delivery Time | 20-30 days. Standard size is in stock,prompt delivery or as order's quantity. |
| Package | Export standard package, Carton box or wooden case, or waterproof paper, or as customer's request. |
| The inner size of container is below: | |
| 20ft GP: 5.9m(length) x 2.13m(width) x 2.18m(high)about 24-26CBM | |
| 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM |
Mechanical behavior
|
Tensile strength (MPa) |
Yield strength (MPa) |
Hardness HB |
Elongation （%） |
|
228 |
193 |
60 |
12-20 |
Physical properties
|
Density |
Melting point |
Modulus of elasticity |
Thermal conductivity |
Resistivity |
|
2.68 Kg/m³ |
605 °C |
70 GPa |
138 W/m.K |
0.0495 x10^-6 Ω.m |
Annealing state
|
Trademark |
Annealing state |
|
1xxx: 1050, 1050A, 1060, 1100 |
O, H12, H14, H16, H18, H22, H24, H26, H28, H111 |
|
3xxx: 3003, 3004, 3005, 3105 |
|
|
5xxx: 5005, 5052, 5754, 5083, 5086, 5182, 5049, 5251, 5454 |
O, H22, H24, H26, H28, H32, H34, H36, H38, H111 |
|
6xxx: 6061, 6082 |
T4, T6, T451, T651 |
|
2xxx: 2024 |
T3, T351, T4 |
|
7xxx: 7075 |
T6, T651 |
Aluminum Production Process
Packing and shipping
