AH36 Carbon steel plate

Category：

Carbon steel plate

WhatsApp:

+8619153118618

Email:

sales68@baotecn.com

Message

Product Description

Product Name	AH36 Carbon Steel Plate
Material	4130、4140、AISI4140、A516Gr70、A537C12、A572Gr50、A588GrB、A709Gr50、A633D、A514、A517、AH36,API5L-B、1E0650、1E1006、10CrMo9-10、BB41BF、BB503、CoetenB、DH36、EH36、P355GH、X52、X56、X60、X65、X70、Q460D、Q460、Q245R、Q295、Q345、Q390、Q420、Q550CFC、Q550D、SS400、S235、S235JR、A36、S235J0、S275JR、S275J0、S275J2、S275NL、S355K2、S355NL、S355JR、S355J0、S355J2、S355G2+N、S355J2C+N、SA283GrA、SA612M、SA387Gr11、SA387Gr22、SA387Gr5、SA387Gr11、SA285GrC、SM400A、SM490、SM520、SM570、St523、St37、StE355、StE460、SHT60、S690Q、S690QL、S890Q、S960Q、WH60、WH70、WH70Q、WQ590D、WQ690、WQ700、WQ890、WQ960、WDB620
Surface	Natural color coated galvanized or customized
Technique	hot rolled or cold rolled
Application	AH36 steel plate is a steel plate with a thickness of no more than 150 mm for the manufacture of ocean going, coastal and inland navigation ships, fishing boats and offshore engineering structures. For steel plates with Z-direction requirements, add Z25 and Z35 to the suffix, which is used as structural steel for high-strength ships and offshore engineering.
Standard	DIN GB JIS BA AISI ASTM EN GOST etc.
Delivery time	Within 7-15 workdays after receiving deposit or L/C
Export packing	Steel strips package or seaworthy packing
Capacity	250,000 tons/year
Payment	T/T L/C, Western Union etc.

Chemical composition

C	Cu	Fe	Mn	P	Si	S
0.25～0.290	0.20	98.0	1.03	0.040	0.280	0.050

Mechanical behavior

AH36	Ultimate tensile strength	Tensile strength, yield strength	Elongation at break (unit: 200mm)	Elongation at break (unit: 50mm)	Elastic Modulus	Bulk modulus (typical value for steel)	Poisson's ratio	Shear modulus
Metric	400～550MPa	250MPa	20.0%	23.0%	200GPa	140GPa	0.260	79.3GPa
Imperial	58000～79800psi	36300psi	20.0%	23.0%	29000ksi	20300ksi	0.260	11500ksi

Physical properties

Physical properties	Metric	Imperial
Density	7.85 g/cm³	0.284 lb/in³

Carbon Steel plate application range

AH36 steel plate is a steel plate with a thickness of no more than 150 mm for the manufacture of ocean going, coastal and inland navigation ships, fishing boats and offshore engineering structures. For steel plates with Z-direction requirements, add Z25 and Z35 to the suffix, which is used as structural steel for high-strength ships and offshore engineering.
AH36 steel plate delivery status
AH36 steel plates are usually delivered in hot rolling, controlled rolling, normalizing and thermo mechanical rolling states
The carbon content of high-strength ship plate steel is less than or equal to 0.18%, while the Mn content is generally 0.6~1.6%. The high-strength steel AH36, DH36, EH32 and EH36 are added with 0.015~0.05% Nb and 0.030~0.10% V. Grade D steel plate can be produced by controlled rolling and controlled cooling process, but the steel plate with thickness greater than 35mm generally requires normalizing treatment.

Packing & Delivery
The Carbon steel sheet will be packed in seaworthy packing such as steel strips bundles. If you have any special requests
on this, please let us know advanced. We will refer to your email kindly.

1).20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)

2).40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)

3).40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

Packing and shipping

The company is located in the Free Trade Pilot Zone of Jinan City, Shandong Province, close to China's famous ports of Tianjin Port and Qingdao Port. It has a superior production and operation environment, convenient logistics exports, mature industrial facilities, and complete supporting industries.
